Appendix
— Parts Breakout – Control Box
CAUTION:
DO NOT connect the operator to
110/120V power. The variable frequency drive is
not setup to handle the lower, single phase
power supply and damage to the unit may occur
which is not covered by the Limited Warranty.
New Membrane switch
(keypad)
Transformer
Power Supply
Contactor
HY-5A
HY-5A
HY-5A
HY-5A
Reset switch
Power switch
Smart Touch Controller
