SlideDriver 10, 30, 40, 80, 200

(222, 333, 444)

Slow down limit ramp. All models
of SlideDriver 50VF-series

Extended slow down limit ramp.

All models of SlideDriver 50VF-series

Figure 1-2. SlideDriver Limit Ramp Configurations

Standard limit ramp
All models of SlideDriver
(Fasten with 2 bolts & 2 nuts)

Slow down limit ramp
(2 bolts & 2 nuts)

Extended limit ramp
(1 bolt, one nut)

Slow down
limit ramp
(2 bolts & 2 nuts)

(Bevel not shown)

Approximately 4 inch (10 cm) spacing
between bolts. If snow blades are attached
to the chassis, countersink the bolts.
