SlideDriver Quick Start
These instructions are provided as a quick reference guide for the experienced installer who is already familiar with
all safety precautions and the installation of this gate operator.
CAUTION: Use this QuickStart as a guide and read and follow the information and instructions found in
the other sections of this manual. DO NOT attempt to connect this operator to any voltage other than that
listed on the nameplate. Be certain the labeled voltage and phase of the operator matches the available
supply. For assistance, contact HySecurity Technical Support at 800-321-9947.
Refer to the Technical Drawings on pages 15 - 17 when proceeding through the following steps:
1. Mount the operator with at least four mounting bolts. The operator must be square and spaced 1¾ inches (44mm) away
from the gate.
2. Attach the drive rail to every vertical member of the gate at a height 9¼ inches (24cm) above the base of the operator.
Use ¼ " (6mm) roll pins to splice multiple sections of rail.
3. Mount the limit switch stop ramps to the underside of the drive rail at each end (flat side up, tapered end toward the
wheel) in the drive rail slot closest to the operator. Drill ⅜" (9mm) holes in a position that will allow the limit switches to be
tripped 6 to 8 inches (15 to 20cm) before full travel.
4. Connect the electrical power wires to the loose wires from the ON/OFF switch at the left corner of the control box and
attach the grounding wire to the green grounding wire. Be certain the labeled voltage and phase of the operator matches
the available supply.
5. Operators are shipped hydraulically configured for “right hand” operation. (From the secure side, the gate moves to right
on opening). To change the handing, reconnect the hydraulic hoses at the pump in reverse order. There is a label near
the hose quick disconnect fittings that describe this procedure. Connecting the hose from the top motor to the left
disconnect fitting r
esults in “left hand” operation.
6. With neither limit switch tripped, engage the release mechanism to clamp the wheels to the drive rail and verify that the
red spring is compressed to 2 inches (5cm) in height.
7. Turn ON the power switch. The UL usage class [  ] appears on the Smart Touch Controller display after a two-second
delay. The setting for the usage class must be selected before the gate can function. Press the SELECT button, then the
NEXT button and select a usage class of 1 through 4 as appropriate for the site. Press the SELECT button again to lock
the setting.
8. Press the NEXT button to move to the next menu item and set the gate handing. The characters [ ] appear on the
display. Replace the 0 with [ ] or [] to set the gate handing by following the same button presses described in
step 7.
9. Press the PROGRAM button to exit to Run Mode. One, of a possible three, operator status displays may appear: ,
 or  ( or  appears if a limit switch is tripped.)
10. Test the operation of the gate. If the hoses are connected incorrectly, the gate will move the wrong direction. (See step 5.)
If the gate moves in the correct direction, but triggers an  alert, the handing is set wrong. (See step 8.)
11. After normal operation has been verified, connect any required accessory device wiring. Note that the control inputs
(except Fire Department Open and Emergency Close) are all one wire only to the main terminal strip while the other wire
connects to the Common Bus (COM) on the nearby power supply board.
12. To access the User Menu, press the PROGRAM button while there is no active Open or Close input. The operator status
displays scroll past and stop at the [ ] Close Timer menu item. If a Close Timer function is needed, set it in the same
manner as above.
NOTE: The Close Timer display is the initial menu in the “User Menu” which contains 12 menu items. Access to the 34
items in the “Installer Menu” is also accessible from the Close Timer display by simultaneously pressing the RESET and
OPEN buttons. The Usage Class [  ] which is the first menu item in the Installer Menu appears. Read the instructions
found in this manual before attempting any adjustments!
