2 © 2012 Installation and Reference Manual D0119 Rev. J
Descriptions of Various Models Derived from SlideDriver 10
For Heavy Gates: SlideDriver 40 222 E Models (UL class I, II, III, and IV)
This model uses a hydraulic manifold with two adjustable brake valves. The brake valves extend the maximum gate
weight capacity from 1,000 pounds to up to 4,000 pounds. Brake valves are highly recommended for heavy-duty
applications.
High Speed: SlideDriver 30F 222 EX 1.7 Models (UL class III and IV only)
The AWOG Soft Starting system and brake valves are keys to safely moving gates faster than one foot per
second. These devices, together with our hydraulic drive, create smooth and predictable handling for both small,
lightweight to 3,000 lb. gates. The SlideDriver 30F, 30F-C, and 30F UPS models use a higher flow rate pump to
achieve a speed of 20 inches per second.
High Speed, Very Heavy: SlideDriver 50VF2, 50VF2-EFO, and 50VF3
UL class III & IV only.
These operators are designed for very heavy, up to 5,000 lbs gates moving at high and very high speeds.
The variable frequency drive moves very heavy gates at the following speeds:
26 inches per second, 50VF2
26 inches per second, 50VF2
– EFO (Close in 36in/s with a constantly held CLOSE command.)
36 inches per second, 50VF3
SlideDriver VF models close gates to a very precise point and are extremely easy on gate hardware. SlideDriver
VF operators use a variable frequency drive, larger wheels and a higher flow rate pump to reach 26 to 36 inches
per second. These operators use the same powerful HySecurity Smart Touch controller and simple and reliable
hydraulics of all SlideDriver models.
For Heaviest Gate: SlideDriver 200 (444 XS)
The 444 type operators are for the heaviest gates, weighing up to 20,000 lbs. They employ a much
larger chassis with four drive wheels and hydraulic motors, and a five horsepower electric motor to
generate up to 1200 pounds of draw bar pull.
SlideDriver, DC 24-Volt UPS (Uninterruptible Power Supply) (UPS)
These gate operators function from 24 Volts DC Batteries all of the time to achieve a true UPS
system. Our Uninterruptible Power Supply is the most certain way to know that your gate will work
when the local AC power fails. This system features fully sealed maintenance free batteries in a
separate insulated and ventilated enclosure and provides at least 3,000 feet of backup gate travel.
SlideDriver C, Correctional Facility (-C)
The CF models offer an extra heavy 10-gauge cover with three different locking options. Correctional
Facility operators are shipped ready to interface to the many options and interlocks commonly used at
correctional facilities, such as gate position outputs, interlock capability for sally ports and an interface
relay to control an external solenoid lock.
SlideDriver M, Modular (-M)
This family of operators is a two part modular version of the standard SlideDriver operator. The motor,
hydraulic pump and electric controls are located in a separate enclosure, often at a distance from the
drive unit. This version allows for a more flexible placement of the operator, which may be required or
desirable in some situations involving unique mounting, special security (including blast mitigation) or
those areas requiring a very quiet operator.
The Smart Touch Controller
This is the brain of HySecurity operators. Groundbreaking technology combined with sturdy construction to
reliably serve in the harshest environments. The Smart Touch Controller can quickly be configured by an
installer or user to adapt to nearly any site specific functional requirement. All system settings are performed
with the use of four programming buttons and an LCD display. The Smart Touch Controller has no switches to
set. An RS232 port for external communication is standard. An EEPROM records date stamped system events.
A log of events can be downloaded from the RS232 port to a laptop computer to evaluate abnormal gate system
operation. HySecurity HY-5A vehicle detectors set a new industry standard by communicating valuable
performance data to the Smart Touch controller, allowing quick and deep, user-friendly diagnostics.
