51 © 2012 Installation and Reference Manual D0119 Rev. J
Section 7
— Troubleshooting
The Smart Touch Controller includes many self diagnostics. Specific messages appear on the display and the Audio Alert
buzzer sounds distinctive chirps. Any Alerts, Faults or Errors are also logged into memory and date/time stamped. For
diagnostic purposes, these messages can be retrieved with optional START software available from the HySecurity
website. The following chart lists problem codes detected by the Smart Touch Controller. Updates to this chart appear on
HySecurity
’s website at www.hysecurity.com
Error, Fault, or Alert Status
LCD
Display
Reads Buzzer Chirp Sequence
Cannot respond due to tripped IES sensor or
operator is in entrapment mode  Entr 2 chirps/sec every 2 seconds while control input is active
Safety Mode Alert  SAFE 2 chirps once when in Safety Mode
Low 24V Control Voltage Alert (AC or DC)  Lo24 N/A (display flashes 1 sec every 5 seconds)
Critical Low Power (AC or DC )  bAdP 1 chirp every 3s – controls disabled
Dead 24V Battery Alert – DC only  bat – dEAd 3 chirps upon any operating command
Gate Forced Open Alert  ALE1 2 pulses/sec for 30 seconds
Gate drift closed Alert  ALE2 2 pulses/sec for 10 seconds
Motor thermal overload Alert  ALE4 2 chirps/sec once every 15 seconds
Both Limits Tripped Alert  ALE5 2 chirps/sec every 15 seconds
Limits not released in 10 seconds  ALE6 2 chirps/sec every 15 seconds
Loop detector freq change alert  ALE7 2 chirps/sec every 15 seconds
Loop shorted to ground alert  ALE8 2 chirps/sec every 15 seconds
Loop open (disconnected) alert  ALE9 2 chirps/sec every 15 seconds
Loop detector comm. alert  AL10 2 chirps/sec every 15 seconds
Loop detector failed alert  AL11 2 chirps/sec every 15 seconds
Loop detector active >5 minutes  AL12 2 chirps/sec every 15 seconds
General I2C Comm. Buss failure  AL16 2 chirps/sec every 15 seconds
Bad 3V coin battery  AL17 2 chirps/sec every 15 seconds
False slow down signal  AL19 2 chirps/sec every 15 seconds
Lock Intrlk (Input #22) Blocks Open  AL20 2 chirps/sec every 15 seconds
VFD Error Alert  AL21 2 chirps/sec every 15 seconds
Dual/Seq. Gate communication lost  AL22 2 chirps/sec every 3 seconds
Maximum Run Fault  FAL1 1 chirp once every 15 seconds
Photo eye Fault (supervised)  FAL2 2 chirps/sec once per minute
Critical AC sag – bad supply wire  FAL3 2 chirps/sec once per minute
Open or Closed limit failed  FAL5 2 chirps/sec once per minute
Directional Motion Error  Err1 3 chirps/sec once per minute
Disconnected IES Error  Err2 3 chirps/sec once per minute
Serial comm. internal Error  Err3 3 chirps/sec once per minute or 3 on Cmd.
Serial comm. mast/slave Error  Err4 3 chirps/sec once per minute
STC-VFD Communications Error  Err6 3 chirps/sec once per minute
EEPROM Data Error (factory)  Err7 3 chirps/sec once per minute
EEPROM Data Error (installer)  Err8 3 chirps/sec once per minute
EEPROM Data Error (user menu)  Err9 3 chirps/sec once per minute
Open or Close slow down switch failed  Er10 3 chirps/sec once per minute
Memory Checksum Error  Fail 3 chirps/sec once per minute
NOTE: The green LED near the “coin” battery on Smart Touch Controller is the “heartbeat” of the processor. This LED
always blinks at a steady pace which indicates normal operation.
Gate Speed: The gate speed is determined by the size of the hydraulic operator’s pump and its actuator components. Just like a gear
box, this speed is not adjustable. Do not attempt to slow a gate by changing a valve setting. If the speed of a gate must be changed,
contact your HySecurity distributor. Extremes in temperature usually does not affect the speed of the gate. HySecurity hydraulic gate
operators use a special fluid called Uniflow, which maintains a linear viscosity over a broad range of temperatures. HySecurity operators
are rated for service in ambient temperatures of -40°F to 158°F. If the speed of your operator is affected by temperature, verify that the
gate hardware is not impaired and check that the reservoir is filled with Uniflow. Consider adding a heater in extreme weather.
