Section 3
—Installer Menu Functions – continued
Installer 17 [
] PEO (photo eye open) reverse to close: The default setting is non-reversal if the open photo eye
is triggered. The optional setting of [
] will cause the gate to reverse to close for two seconds if triggered while opening.
Installer 18 [gr 0] Edge reverse to open: The default setting is to reopen fully. The optional setting of [
] sets the
gate at a 2-second reversal if triggered while closing.
Installer 19 [
] IES (inherent sensor) reverse to open: The default setting is a 2-second duration reversal if the
inherent sensor is triggered. The optional setting of [
] will cause the gate to reopen fully if triggered while closing.
Installer 20 [
] Set PEO/ PEC – NO/NC: The default setting is photo eyes with Normally Open outputs. The
optional setting [
] will require a Normally Closed (NC) output. If set for NC, the connection is also supervised and any
open or short circuit fault will generate a FAL2 alert, which requires a Stop button reset to re-enable any function if
triggered.
Installer 21 [
] Set Edge input – NO/NC: The default setting is edge sensor with Normally Open (NO) outputs. The
optional setting [
] will require a NC output..
Installer 22 [
] Time clock / Interlock input: This menu item configures the input at terminal #7 to be either for the
gate interlock function, as described on page 29, or for an external time clock to open input, as described on page Error!
Bookmark not defined.. The default setting is [
for the interlock function.
Installer 23 [
] Disable Free Exit / Close timer: Configures the input at Terminal No. 9 on the controller circuit board
to disable either the Free Exit Detector on terminal #8, or the Timer To Close function. Default setting is [
] allowing
disabling of the free exit detector.
NOTE: The free exit is disabled when the gate is at its closed limit. If the closed limit is not tripped, the free exit continues
to work.
Installer 24 [
] OOLD (Outside Obstruction Loop Detector) function: The default is for full reversal when the
OOLD is triggered. The optional setting [
] causes the gate to only pause when triggered. Gate closure begins as
soon as the loop is clear again.
Installer 25 [
] IOLD (Inside Obstruction Loop Detector) function: The default is for full reversal when the IOLD
is triggered. The optional setting [
] causes the gate to only pause when triggered. Closure begins as soon as the
loop is clear again.
Installer 26 [
] Vehicle detector logic: Configures quick close and anti-tailgate logic. There are four modes. See the
full description on page 44.
Installer 27, 28, 29 [
], [], [] User output relay 1 - 3 options: Configures the function of the three user
output relays. The choices are described in detail starting on page 30.
Installer 30 [
] Gate Open alert: Adjusts the time delay before activating the user relay function #8, described on
page 30. Time settings up to 135 seconds.
Installer 31 [
] Loitering alert: This menu item is to adjust the time delay before activating the user relay function
#13, described on page 30. Time settings up to 135 seconds.
Installer 32 [
] System Address: Sets the system address for network communication; 0 = no network
communication, 1-99 sets individual poling addresses. Requires v4.24 software or higher.
Installer 33 [
] Factory ELD: Controls the HY-5A Free Exit detector, see page 43.
Installer 34 [
] Factory IOLD: Controls the HY-5A IOLD detector, see page 43.
Installer 35 [
] Factory OOLD: Controls the HY-5A OOLD detector, see page 43.
Installer 36 [SLd]. Factory SLD: Controls the HY-5A Shadow detector, see page 43.
