MCNConfig Program: Display Windows
79 68-11824-210
Hit the Add button.
This will add the receivers all at once,..
Automatic Linking to Receiver Window
As you select different cells in the Display Window, the receiver window scrolls so that that receiver or
I/O group is visible.
Verifying Receiver Placement
Many systems have receivers from many channels at each site. Since only a Receiver site name or I/O
Group name is present in the Display Window, it is not readily apparent which particular receiver or I/O
point is in a particular cell. You can quickly check the contents of the Display Window by doing the
following:
Open the Display Window
Open the Receiver Window.
Select the first Receiver in the Display Window.
The Receiver Window will show which receiver is at that cell.
Use the arrow keys to move through all the receivers on the Display Window.
Repeat for the other tabs in the Display Window.
Adding Display Tabs
Press the Add Tab button.
Enter the name for the new tab.
A blank grid will appear.
