CTI Products RCD Advanced Client-Server User Manual
Page 150
MCN Server Program
150
68-11824-210
Additional HIB-IP Diagnostic Functions
When you Right-Click on a HIB-IP Network Interface, you have two additional diagnostic options:
Wink and CSVC.
Wink
This will blink the "Wink" LED on the front of the HIB-IP unit.
This can be helpful to identify a HIB-IP unit when you are using Advanced Server software
with multiple HIB-IP units.
CSVC This is the equivalent of pressing the CSVC button on the front of the HIB-IP unit.
In special instances a CTI engineer may instruct you to click on the CSVC function.
Layout Mode
The following figure shows the MCN Server Display Window in Layout Mode.
