Installation
18 68-11824-210
Configure and Test the PCLTA Network Interface
From the Start menu button on the Windows desktop, select Control Panel from the list, then double
click the “LonWorks Plug ‘n Play” icon. (If the “LonWorks Plug ‘n Play” icon is not visible, change the
Control Panel properties to “Classic View”.)
The following “LonWorks Plug ‘n Play” window will be displayed.
In the NI Application drop-down list, choose an image that is compatible with the MCN Server program
from the following table. (For all operating systems, the Image name should end with “L7”.) Then click
the
Apply button.
Windows XP, 2000, or 2003
Images Compatible with MCN Server program PCLTA21L7
Images that will not work PCLTA21VNI, PCL10VNI
To check if the PCLTA network interface has been installed correctly, click the Diagnostics button to
display the following window.
