Installation
31 68-11824-210
HIB-IP Parameters
As shown in the “ Setup HIB-IP ” window above, you will later enter the HIB-IP parameters in the
system database using the McnConfig program. You will also have to download those parameters to the
HIB-IP using McnConfig.
Miscellaneous Installation Considerations
Changing Settings for your Network Interface
If you need to change the settings for your Network interface, re-run the HWSetup program. This
program can be used to change the:
•
Type of Network Interface
•
PCLTA Device or Group & Module address
•
HIB-232 COM Port or Baud Rate
To change these items you can either:
•
Double click on the Network Interface to edit its parameters or
•
Click the Remove button to remove the Network Interface and select a different one.
If you have a Custom Engineered System (with custom system documentation part number KA-8xxxx-
xxx), be sure to set the PCLTA address to the Group & Module numbers shown in your documentation.
Failure to do so may cause the system not to work
In the above window, click the Next button
PC Power Options Setup
The “Power Options” icon in the Control Panel allows for a wide variety of PC operation parameters.
However, installation of MCN Server software will disable any possibility of the PC going into a
standby or hibernate condition.
The monitor may be allowed to “sleep” as long as the “Monitor Timeout” is less than the “Standby
Time”. Otherwise, the monitor will never sleep.
Printer Installation
For printer logging to occur, a printer must be installed from the Windows operating system. From the
Start menu button on the windows desktop, select “Printers and Faxes” from the list, then select “Add a
Printer” from the list of “Printer Tasks”.
