Specifications
Specifications are subject to change without notice.
Specification
Details
Operating temperature
-5°C to +40°C
Storage temperature
-20°C to +70°C
Operating humidity
0 to 95% non condensing relative humidity
Operating altitude
From 0 to 2,000 m. (6,550 ft.) above sea level
EMC requirements
EN61326-1:2006 Directive 2004/108/EEC
Note: The wall mount instrument is a Class A product. In a domestic environment this
product may cause radio interference in which case the user may be required to take
adequate measures.
CE compliance
EN61010-1: 2010 Directive 2006/95/EEC
Safety rating
ETL, conforming to UL 61010-1 and CSA 22.2 No. 61010-1
Enclosure ratings
IP 65; Totally protected against dust; Protected against low pressure jets of
water from all directions.
Note: For portable models, IP 65 is applicable only when a cable is connected to the
ethernet socket.
NEMA 4X (wall mount only); Totally protected against dust; Protected against
pressure jets of water from all directions.
Power supply
Wall and panel mount
Universal 100 VAC to 240 VAC @ 50/60 Hz - 40VA 10 to 30 VDC - 30W
Power supply
Portable
5V supplied through an external power supply 100-240 VAC @ 50/60 Hz - 1A
Optional battery pack with 4 hour autonomy (charges in about 6 hours). Battery
charge time can increase at T > 30°C.
Analog current output version
on the measurement board(s)
4-20 mA (default) or 0-20 mA (configuration with software);
3 configurable outputs: Maximum load: 500 ohm; Sensitivity: 20μA;
Accuracy: ± 0.5% (between operating temperature limits)
Analog voltage output version
on the measurement board(s)
0- 5 V output (hardware option);
3 configurable outputs; Minimum load: 10 KOhm; Sensitivity: 5 mV;
Accuracy: ± 0.5% (between operating temperature limits)
Measurement alarm relays on
the measurement board(s)
Three alarm relays per measurement board; 1A-30 VAC or 0.5A-50 VDC on a
resistance load.
Configurable to Normally Open [NO] or Normally Closed [NC] contacts by
changing the jumper positions.
W A R N I N G
Potential Electrocution Hazard. Connect only safety low voltage < 33 VAC
RMS
System alarm relay on the main
board
One system alarm relay; 1A-30 VAC or 0.5A-50 VDC on a resistance load.
Normally closed [NC] (NO relay also available) when instrument is turned on.
W A R N I N G
Potential Electrocution Hazard. Connect only safety low voltage < 33 VAC
RMS
Options
RS-485 or PROFIBUS-DP; USB client; USB host; Ethernet 10/100 Base-T
Wall and pipe mount instrument
(H x D x W)
236.5 x 160 x 250 mm - weight 3.8 kg
9.31 x 6.30 x 9.84 ins. - weight 8.38 lbs
