Option Description
User action logging When enabled every action from a logged on user is recorded in a user log file.
User action log file The log file is a rolling buffer recording recent actions. Press Clear to empty the log
file.
User management
Select Access table from the Security menu to show the list of registered users (a maximum of
99 users allowed). They are listed by name, ID, password and access level.
Pressing on an empty line or the Add button displays a window to add a new user. User name, ID,
password (minimum 4 characters) and access level (1 to 4) are required.
Pressing on a registered user displays a window for editing or deleting that user.
View menu
Numeric view
This is the default view and shows the numeric measurement value identified for each gas
measurement channel available, a graphic showing measurement value evolution during the set time
frame, and sample temperature. The display is refreshed after each measurement cycle which can
be configured to suit user requirements. Select Configure from the View menu followed by Conf.
numeric view to customize the display.
Statistic view
This feature offers statistical data to match with Total Quality Management tools to better analyze
how a process behaves. The statistics are calculated from the data in the measurement file and
values updated each time a new measurement is added.
Diagnostic view
The diagnostic view contains important information but is only really useful for troubleshooting
purposes.
Measurement menu
Instrument configuration
TPO or TPA calculation (portable instrument)
The TPO (Total Package Oxygen) and TPA (Total Package Air) features are available on the
portable instrument for an EC sensor measuring oxygen. To initiate these options, the instrument
must be configured in Sample mode and the TPO or TPA calculation must be enabled. The operator
also needs to ensure the package is shaken for about 5 minutes before measuring, and to know the
total volume of the package and the total volume of the contents of the package.
Continuous mode or sample mode (portable instrument)
Continuous mode is typically used for process measurement, whereas sample mode is aimed at lab
measurements of small volume individual samples such as cans, bottles, etc. The measurement
mode is a parameter defined for the entire instrument, not for each channel.
Continuous or sample mode selection
1. Select Config. instrument from the Measurement menu:
Option Description
Measurement mode Continuous mode for on line process.
Sample mode for lab sample analysis (portable instruments only).
14 English
