12. Ordering Information
Mfr. Part No. Code Description
3-2850-51 159 001 398 2850 Sensor Electronics w/ Digital Output and ¾ inch adapter
3-2850-52 159 001 399 2850 Sensor Electronics w/ 4 to 20 mA Output and ¾ inch adapter
3-2850-61 159 001 400 2850 Sensor Electronics w/ Digital Output and Universal adapter
3-2850-62 159 001 401 2850 Sensor Electronics w/ 4 to 20 mA Output and Universal adapter
3-2850-63 159 001 402 2850 Sensor Electronics w/ Dual Inputs, Digital Outputs and Universal adapter (see NOTE)
3-2850-51-39 159 001 339 Integral 2850 system, Digital (S 3 L) output, 0.01 cell, NPT threads
3-2850-51-40 159 001 340 Integral 2850 system, Digital (S 3 L) output, 0.1 cell, NPT threads
3-2850-51-41 159 001 341 Integral 2850 system, Digital (S 3 L) output, 1.0 cell, NPT threads
3-2850-51-42 159 001 342 Integral 2850 system, Digital (S 3 L) output, 10.0 cell, NPT threads
3-2850-51-39D 159 001 343 Integral 2850 system, Digital (S 3 L) output, 0.01 cell, ISO threads
3-2850-51-40D 159 001 344 Integral 2850 system, Digital (S 3 L) output, 0.1 cell, ISO threads
3-2850-51-41D 159 001 345 Integral 2850 system, Digital (S 3 L) output, 1.0 cell, ISO threads
3-2850-51-42D 159 001 346 Integral 2850 system, Digital (S 3 L) output, 10.0 cell, ISO threads
3-2850-52-39 159 001 347 Integral 2850 system, 4 to 20 mA output, 0.01 cell, NPT threads
3-2850-52-40 159 001 348 Integral 2850 system, 4 to 20 mA output, 0.1 cell, NPT threads
3-2850-52-41 159 001 349 Integral 2850 system, 4 to 20 mA output, 1.0 cell, NPT threads
3-2850-52-42 159 001 350 Integral 2850 system, 4 to 20 mA output, 10.0 cell, NPT threads
3-2850-52-39D 159 001 351 Integral 2850 system, 4 to 20 mA output, 0.01 cell, ISO threads
3-2850-52-40D 159 001 352 Integral 2850 system, 4 to 20 mA output, 0.1 cell, ISO threads
3-2850-52-41D 159 001 353 Integral 2850 system, 4 to 20 mA output, 1.0 cell, ISO threads
3-2850-52-42D 159 001 354 Integral 2850 system, 4 to 20 mA output, 10.0 cell, ISO threads
Parts and Accessories
Mfr. Part No. Code Description
3-9000.392-1 159 000 839 Liquid-tight connector kit, 1 set, 1 /
2
in. NPT
3-9000.392-2 159 000 841 Liquid-tight connector kit, 1 set, PG 13.5
3-2850.101-1 159 001 392 Plug-in NIST-traceable recertifi cation tool, 1.0 μS
3-2850.101-2 159 001 393 Plug-in NIST-traceable recertifi cation tool, 2.5 μS
3-2850.101-3 159 001 394 Plug-in NIST-traceable recertifi cation tool, 10.0 μS
3-2850.101-4 159 001 395 Plug-in NIST-traceable recertifi cation tool, 18.2 MΩ
3-2850.101-5 159 001 396 Plug-in NIST-traceable recertifi cation tool, 10.0 MΩ
82 mm
(3.24 in.)
95 mm
(3.74 in.)
85 mm
(3.34 in.)
95 mm
(3.74 in.)
3-2850-61
3-2850-62
3-2850-63
Electronics w/Universal adapter
3-2850-51
3-2850-52
Electronics w/ ¾-in. adapter 3-2850-51-XX
3-2850-52-XX
Integral System
Cond. - Resist.
Simulator
@ 25°C
For use with Signet
2850 Conductivity
NIST Traceable
3-2850.101-X
NIST-traceable
recertifi cation tool
NOTE: Dual-input unit (3-2850-63) is available only in the universal adapter confi guration with Digital S 3 L output for use with the 8900
Controller.
