Spare Parts
20. spare parTs
Caution!
risk of injury and/or damage by the use of incorrect parts!
Incorrect accessories and unsuitable spare parts may cause injuries and damage the device and the sur-
rounding area.
Use original accessories and original spare parts from Bürkert only. •
item no. spare parts id no.
1 O-ring 100 x 1.78 EPDM 797946
2 8681-24V module, casted + programmed 196480
2 8681-AS interface module, casted + programmed 196481
2 8681-DeviceNet module casted + programmed 196482
2 8681-120V module casted + programmed 196483
3 Adapter compl. with Valve 6524 (incl. throttle module) 797935
4 Position measuring sensor with PCB (LDR-85-BUE) 797885
(5) Light conductor (Plexiglas) 797889
(6) Cable with 12-pole plug M12 (IEC 61076-2-101), approx. 8 cm (24 V DC) 217574
(6) Cable with 4-pole plug M12 (IEC 61076-2-101), approx. 8 cm (AS interface) 217573
(6) Cable with 4-pole plug M12 (IEC 61076-2-101), approx. 80 cm (AS interface) 217572
(6) Cable with 5-pin plug M12 (IEC 61076-2-101), approx. 80 cm (DeviceNet) 218187
(10) Cover, coated, with logo 796053
11 Shoulder screw M5 (with pin) 797919
12 Square nut DIN 562 115 197723
1
2
3
4
12
11
