24 V DC - Design
design aid
10.3.
power consumption of the electronics:
P
El
= 0.7 W
or
I
El
= 30 mA at 24 V
power consumption of a valve during activation (200 ms):
P
Valve-On
= 0.9 W
or
I
Valve-On
= 38 mA at 24 V
power consumption of a valve after reduction:
P
Valve
= 0.8 W
or
I
Valve
= 34 mA at 24 V
power consumption of an optical position report:
P
LED
= 1.0 W
or
I
LED
= 42 mA at 24 V
Also, if several control head valves were to be opened simultaneously, the switch signal will be sent stag-
gered to the valves. Only
one valve will consume 0.9 W at any time.
Calculation examples:
example 1:
3 valves are activated simultaneously, one position is reported (state for 200 ms):
P
Total
=
P
El
+ 1 x P
Valve-On
+ 2 x P
Valve
+ 1 x P
LED
4,2 W =
0.7 W
+ 1 x 0.9 W
+ 2 x 0.8 W
+ 1 x 1.0 W
or
I
Total
=
I
El
+ 1 x I
Valve-On
+ 2 x I
Valve
+ 1 x I
LED
178 mA =
30 mA
+ 1 x 38 mA
+ 2 x 34 mA
+ 1 x 42 mA
example 2:
3 valves have been activated simultaneously, one position is reported (persistent state):
P
Total
=
P
El
+ 3 x P
Valve
+ 1 x P
LED
4.1 W =
0.7 W
+ 3 x 0.8 W
+ 1 x 1.0 W
or
I
Total
=
I
El
+ 3 x I
Valve
+ 1 x I
LED
174 mA =
30 mA
+ 3 x 34 mA
+ 1 x 42 mA
When using an external initiator, its power requirement should be added.
