Introduction
FireWire Hardware Installation Guide V8.0.0
9
continued from last page
V3.0.0 08.10.08 New Stingray F-125B/C:
see Figure 20: Stingray output switching times on page 51
V4.0.0 21.10.08 New Stingray F-504B/C
see Figure 20: Stingray output switching times on page 51
V5.0.0 24.10.08 New Guppy F-503B/C
see Guppy delay on page 74
V5.1.0 28.01.09 New CAD drawings (hexagon socket head cap screw ISO 4762):
• Figure 12: Board level camera (Stingray): two IEEE 1394b
FireWire connectors
on page 42
• Figure 21: Stingray board level camera: I/O pin assignment
on page 53
Added 50 mA as max. input current on page 71.
Dolphin camera family discontinued
V5.2.0 28.05.09 Changed Camera In 1 signal U
in
(high) from 2 V to 2.4 V in Figure
33: Guppy (housing): Camera I/O connector pin assignment on
page 69
Added minimum pulse width (inputs) for all camera families:
• Stingray: see Chapter Stingray delay and minimum pulse
width on page 49
• Pike: see Chapter Pike delay and minimum pulse width on
page 56
• Guppy: see Chapter Guppy delay and minimum pulse width
on page 72
• Marlin: see Chapter Marlin delay and minimum pulse width
on page 78
• Oscar: see Chapter Oscar delay and minimum pulse width
on page 84
to be continued on next page
Version Date Remarks
Table 1: Document history
