Safety instructions
FireWire Hardware Installation Guide V8.0.0
21
Pike/Oscar: changing filters safety instructions
Marlin/Stingray/Guppy PRO: changing filters
safety instructions
Note
•
Pike/Oscar models only: Changing filters is achieved by
changing back focus rings with the appropriate filter
already mounted. Please be advised that back focus
adjustment will be necessary in order to match C-Mount
distance of 17.526 mm. Ask your dealer for further infor-
mation or assistance.
Note
•
Marlin/Stingray/Guppy PRO models only: For certain
applications it may be recommended to take out the filter
by means of a special tool which can be ordered from AVT
under the following number: E9020001.
•
Taking out the filter requires special care. Ask your dealer
to help you if you are not confident with the procedure.
