Camera interfaces
FireWire Hardware Installation Guide V8.0.0
56
Pike delay and minimum pulse width
The cycle delay for all Pike cameras (except Pike F-505) is:

tpdLH
 2.2 μs and tpdHL  2.9 μs
The minimum pulse width for all Pike cameras (inclusive Pike F-505) is:

tp
 2.0 μs
Test conditions
The input signal was driven with 12 V and a 2.2 k
 pull down resistor to GND.
Parameter Value
Initial on-current 5 mA
Flux voltage of the LED (@ 10 mA) 1.5 V
Maximum off-current 0.25 mA
Maximum input current 15 mA
Table 11: Pike: input parameters
