Camera I/O connectors (8 pin) order numbers
and cables: Guppy
The 8-pin camera I/O connector (only Guppy cameras) is designed for industrial
use.
It provides:
•
access to the inputs and outputs on the camera
•
a serial interface
AVT also supplies various I/O cables of different lengths.
www
For more information on cables and on ordering cables
online (by clicking the article and sending an inquiry) go to:
Note
For pinning of the I/O connectors as viewed in pin direction see
Chapter
