Introduction
FireWire Hardware Installation Guide V8.0.0
10
continued from last page
V5.3.0 16.09.09 New Stingray front flange:
• Title page: new Stingray photo
• Table 4: How to remove the filter/protection glass on page
28 (new: Stingray Rev. 3)
• Figure 12: Board level camera (Stingray): two IEEE 1394b
FireWire connectors
on page 42
• Figure 21: Stingray board level camera: I/O pin assignment
on page 53
New Pike front flange:
• Title page: new Pike photo
• Table 4: How to remove the filter/protection glass on page
28 (Pike Description: both screws top (middle) and the
right side)
V6.0.0 07.05.10 Minor corrections:
• Corrected Camera Input 1: U
in
(high) = 3.8 V...5 V

U
in
(low) = 0 V...1 V in Figure 33: Guppy (housing): Camera
I/O connector pin assignment on page 69
Added Pike F-1100 and Pike F-1600:
• Title page: photo of Pike F-1000/F-1600
• Pike delay on page 60
Discontinuation of Marlin F-131C
New links to new AVT website
• Chapter Contacting Allied Vision Technologies on page 6
to be continued on next page
Version Date Remarks
Table 1: Document history
