Chapter, Camera i/o connectors (12 – ALLIED Vision Technologies Oscar F-810 User Manual

Page 45

Camera interfaces

FireWire Hardware Installation Guide V8.0.0

Camera I/O connectors (12 pin) order numbers
and cables: Guppy PRO, Stingray, Pike, Marlin,
Oscar

The 12-pin camera I/O connector (Guppy PRO, Stringray, Pike, Marlin, Oscar) is
also designed for industrial use and, in addition to providing access to the
inputs and outputs on the camera, it also provides a serial interface for e.g. the
firmware update.

The connector is available in straight and angled version.

Note



AVT supplies suitable I/O cables of different lengths (up to
10 m) as shown below.

www



For more information on cables and on ordering cables
online (by clicking the article and sending an inquiry) go to:

http://www.alliedvisiontec.com/emea/products/
accessories/firewire-accessories.html

Note



For pinning of the I/O connectors as viewed in pin direction
see:

•
