Introduction
FireWire Hardware Installation Guide V8.0.0
8
continued from last page
V2.2.0 19.08.08 Inserted Latching precautions for 1394a cables in Chapter Con-
necting camera to PC or laptop on page 35
Corrected ordering number in Figure 3: Removing IR cut filter/
protection glass using special tool (E9020001) on page 29
Restructuring Chapter Camera interfaces on page 37ff.
New measurements of inputs and outputs and standardized
descriptions of I/Os for all AVT camera families in Chapter
Cam-
era interfaces on page 37ff.
New photo of Stingray camera with new screws on either side of
the camera on title page
New photo of Stingray backside in Figure 8: Example: Rear view
of Stingray camera (2x 1394b copper) on page 37
New photos of Dolphin, Oscar, Marlin, Guppy, Pike, Stingray
(with HIROSE and 1394 copper) in
Table 5: Rear view of AVT cam-
eras (HIROSE and 1394 copper) on page 38
New photos Pike fiber and Stingray fiber (with HIROSE and 1394b
GOF and 1394b copper) in
Table 6: Rear view of AVT cameras
(HIROSE and 1394b GOF/copper) on page 38
New photo of Pike fiber (with HIROSE and 1394b GOF and 1394b
copper) in
Figure 15: Rear view of Pike camera (1394b: 1 x GOF, 1
x copper) (Stingray similar) on page 44
Deleted AVT Direct FirePackage in Chapter AVT software on page
15
Revised Chapter AVT software on page 15f.
New Stingray board level CAD drawings (1394b connectors are
now (partially) visible):

in Figure 12: Board level camera (Stingray): two IEEE 1394b Fire-
Wire connectors on page 42 and

in Figure 21: Stingray board level camera: I/O pin assignment on
page 53
V2.3.0 12.09.08 New Stingray board level CAD drawing with new Molex 1.25 mm
Pitch PicoBlade Wire-to-Board Header (53047-1310) and new
cable lengths in
Figure 12: Board level camera (Stingray): two
IEEE 1394b FireWire connectors on page 42 and in Figure 21:
Stingray board level camera: I/O pin assignment on page 53
to be continued on next page
Version Date Remarks
Table 1: Document history
