S-Parameter Measurement
Corrected system performance
The specifications in this section apply for measurements made with the Agilent
E5061B network analyzer with the following conditions:
• No averaging applied to data
• Environmental temperature of 23 °C ±5 °C, with less than 1 °C deviation from
the calibration temperature
• Response and isolation calibration not omitted
Table 1. System dynamic range 1,2
Description Specification SPD
System dynamic range
(Option 3L5)
100 kHz to 1 MHz, 3 kHz IF bandwidth 90 dB
1 MHz to 3 GHz, 3 kHz IF bandwidth 95 dB
5 to 100 Hz, 2Hz IF bandwidth 90 dB
100 Hz to 9 kHz,10 Hz IF bandwidth 100 dB
9 to 100 kHz, 10 Hz IF bandwidth 110 dB
100 kHz to 1 MHz, 10 Hz IF bandwidth 115 dB
1 MHz to 3 GHz, 10 Hz IF bandwidth 120 dB 130 dB
(Option 115, 135, 215, 235, 117, 137, 217, 237)
100 to 300 kHz, 3 kHz IF bandwidth 75 dB
300 kHz to 1 MHz, 3 kHz IF bandwidth 90 dB
1 MHz to 3 GHz, 3 kHz IF bandwidth 95 dB
100 to 300 kHz, 10 Hz IF bandwidth 100 dB
300 kHz to 1 MHz, 10 Hz IF bandwidth 115 dB
1 MHz to 3 GHz, 10 Hz IF bandwidth 120 dB 130 dB
1. The test port dynamic range is calculated as the difference between the test port rms noise fl oor
and the source maximum output power. The effective dynamic range must take measurement
uncertainty and interfering signals into account.
2. The specifi cation might not be met at the frequencies 1.4 MHz, 4.0 MHz, 4.333 MHz, 6.333
MHz, 25MHz and 90 MHz.
