13
Test port output (Source)
Table 11. Test port output frequency
Description Specification Typical
Range (Option 3L5) 5 Hz to 3 GHz
Range (Option 115, 135, 215, 235,
117, 137, 217, 237) 100 kHz to 3 GHz
Resolution 1 mHz
Source stability ±7 ppm (5 to 40 °C)
CW accuracy ±7 ppm ±1 mHz
High stability option (Option 1E5)
CW accuracy
±1 ppm ±1 mHz
Stability ±0.05 ppm (5 to 40 °C)
±0.5 ppm per year
Table 12. Test port output power
Description Specification Typical
Level accuracy
(Option 3L5) ±0.8 dB (at 0 dBm, 50 MHz absolute)
±1.0 dB (at 5 Hz to 1.5 GHz, 0 dBm,
relative to 50 MHz)
±1.5 dB (at 1.5 GHz to 3 GHz, 0 dBm,
relative to 50 MHz)
Level accuracy
(Option 115, 135, 215,
235) ±0.8 dB (at 0 dBm, 50 MHz absolute)
±1.5 dB (at 100 kHz to 300 kHz, 0 dBm,
relative to 50 MHz)
±1.0 dB (at 300 kHz to 3 GHz, 0 dBm,
relative to 50 MHz)
Level accuracy
(Option 117, 137, 217,
237) ±0.8 dB (at 0 dBm, 50 MHz absolute)
±1.5 dB (at 100 kHz to 300 kHz, 0 dBm,
relative to 50 MHz)
±1.0 dB (at 300 kHz to 2 GHz, 0 dBm,
relative to 50 MHz) ±1.0 dB (at 2 GHz to
3 GHz, 0 dBm,
relative to 50 MHz)
Level Lineality
(Option 3L5) ±0.75 dB (at –10 to 10 dBm, 0 dBm reference)
Level Lineality
(Option 115, 135, 215,
235, 117, 137, 217, 237) ±0.75 dB (at –10 to 5 dBm, 100 kHz to 300
kHz, 0 dBm reference)
±0.75 dB (at –10 to 10 dBm, 300 kHz to 3 GHz,
0 dBm reference)
Range
(Option 3L5) –45 dBm to 10 dBm
Range
(Option 115, 135, 215,
235, 117, 137, 217, 237) –45 dBm to 5 dBm (at 100 kHz to 300 kHz)
–45 dBm to 10 dBm (at 300 kHz to 3 GHz)
Sweep Range
(Option 3L5) –45 dBm to 10 dBm
Sweep Range
(Option 115, 135, 215,
235, 117, 137, 217, 237) –45 dBm to 5 dBm (at 100 kHz to 300 kHz)
–45 dBm to 10 dBm (at 300 kHz to 3 GHz)
Level resolution 0.05 dB
Table 13. Test port output signal purity
Description Specification Typical
Harmonics (2nd or 3rd) < –25 dBc (at 5 dBm)
Non-harmonic spurious < –25 dBc (at 5 dBm)
