Measurement throughput summary
Table 36. Typical cycle time for measurement completion 1, 2 (ms) (Display update: off)
Number of points
51 201 401 1601
Start 1 GHz, stop 1.2 GHz, 30 kHz IF bandwidth
Uncorrected 5 15 26 89
2-port cal 14 33 56 181
Start 1 GHz, stop 1.2 GHz, 300 kHz IF bandwidth
Uncorrected 4 9 15 43
2-port cal 11 21 33 88
Start 1 MHz, stop 3 GHz, 30 kHz IF bandwidth
Uncorrected 10 23 37 119
2-port cal 24 48 78 241
Start 1 MHz, stop 3 GHz, 300 kHz IF bandwidth
Uncorrected 9 17 26 73
2-port cal 20 37 54 148
Table 37. Typical cycle time for measurement completion 1 (ms) (Display update: on)
Number of points
51 201 401 1601
Start 1 GHz, stop 1.2 GHz, 30 kHz IF bandwidth
Uncorrected 45 47 49 103
2-port cal 55 59 69 195
Start 1 GHz, stop 1.2 GHz, 300 kHz IF bandwidth
Uncorrected 45 47 50 64
2-port cal 55 59 64 103
Start 1 MHz, stop 3 GHz, 30 kHz IF bandwidth
Uncorrected 45 47 50 133
2-port cal 55 61 90 255
Start 1 MHz, stop 3 GHz, 300 kHz IF bandwidth
Uncorrected 45 47 50 87
2-port cal 55 59 67 163
1. Typical performance.
2. Measured with the fi rmware revision A.02.00.
