16
Table 18. Test port input (dynamic accuracy)
Accuracy of the test port input power reading is relative to –10 dBm reference input
power level.
Description Specification Typical
Dynamic accuracy magnitude
(Option 3L5)
Reference = –10 dBm ±0.303 dB
(at 10 dBm)
±0.087 dB
(at –30 dBm)
±2.141 dB
(at –100 dBm)
Dynamic accuracy magnitude
(Option 115, 135, 215, 235, 117, 137, 217, 237)
Reference = –10 dB ±0.303 dB
(at 10 dBm)
±0.087 dB
(at –30 dBm)
±2.141 dB
(at –100 dBm)
300 kHz to 3 GHz
±0.383 dB
(at 10 dBm)
±0.167 dB
(at –30 dBm)
±2.221 dB
(at –100 dBm)
100 to 300 kHz
Dynamic accuracy phase (Option 3L5)
Reference = –10 dB ±2.04 °
(at 10 dBm)
±0.58 °
(at -30 dBm)
±16.23 °
(at –100 dBm)
Dynamic accuracy phase
(Option 115, 135, 215, 235, 117, 137, 217, 237)
Reference = –10 dB ±2.04 °
(at 10 dBm)
±0.58 °
(at –30 dBm)
±16.23 °
(at –100 dBm)
300 kHz to 3 GHz
±2.58 °
(at 10 dBm)
±1.11 °
(at –30 dBm)
±16.94 °
(at –100 dBm)
100 to 300 kHz
