7.5.3 Adjusting and Controlling the Alpha FXM
Use submenu #3, the Maintenance submenu (Figure 67 and Figure 68) to control the Alpha FXM and
change selected items to meet your operational needs.
7.5.3.1
From the Main menu, type 3 and press Enter.
Table I — Maintenance Submenu
30 Battery Test Options Starts the battery test and sets how long the test will run. The default setting for the test
depth-of-discharge is 20%, but this can be adjusted from 0 to 100%. For a description of
the battery test, see BATT TEST in Table B.
31 Inverter On/Off Switches the inverter on or off to allow you to prevent a damaging deep battery discharge
or to provide backup battery power to the load. For a description, see INVERTER in
Table B.
You can set a delay before the inverter switches off to allow time for switching off critical
loads. The Set Inverter ON/OFF delay is only available when the Alpha FXM is in the
Battery or Standby modes.
The delay can be adjusted in 1 second steps with a default setting of 0 seconds to a
maximum of 600 seconds (10 minutes). The delay is only available in the Standby or
Battery modes. Once the Alpha FXM returns to the Line mode, the delay resets itself to 0
seconds.
32 Change Password Changes the Alpha FXM password. The factory set password is 1111, which can only
be changed when the Alpha FXM is in Line mode. The password is limited to 4 alpha-
numeric characters in length.
34 Line Qualify Time Lets you set the delay when the Alpha FXM goes from Battery mode to Line mode after
the line becomes requalified. The purpose of this delay is to make sure the line is stable
before the Alpha FXM switches back to it. For a description, see QUAL TIME in Table B.
The default setting is 3 seconds, but you can set this to 3, 10, 20, 30, 40 or 50 seconds.
35 Low Battery Warning
Voltage
Lets you set the Alpha FXM low battery warning voltage by typing in the % battery
voltage level where you want the warning to be triggered. Adjust the setting to match the
batteries you are using and the actual operating conditions.
48V
:
Default 40% -47 VDC
Adjusted in 1% increment – 0.05 VDC
Minimum 0% - 45.0
Maximum 100% - 50.0 VDC
24V
:
Default 40% - 23.5 VDC
Adjusted in 1% increment – 0.025 VDC
Minimum 0% - 22.5 VDC
Maximum 100% - 24.8 VDC
36 Load Shed Timer On/Off Lets you switch the timer contacts on or off. See "Contacts C1 to C2”.in section 2.3.
