7.2.4 Making Measurements
The System Status menu lets you make measurements of various Alpha FXM inputs, outputs, temperatures
and other values.
7.2.4.1 Procedure
1. From the Logo screen go to the SYSTEM STATUS menu.
2. Press the SELECT button to enter the submenu (Table C).
3. Press the SCROLL button to move between items in the submenu. When you reach the item you want
to measure, stop pressing the button. The measurement is automatically displayed on the LCD. It is
automatically updated every 0.5 seconds.
Table C — System Status Menu
LCD display Meaning Description
VIN Input Voltage The line input voltage into the Alpha FXM
VOUT Output Voltage The Alpha FXM output voltage (true RMS).
IOUT AC
Output Current
(AC)
The Alpha FXM AC output current (true RMS).
BATT TEMP
Battery
Temperature
The battery’s temperature (°C).
FREQ IN Input Frequency The frequency of line power into the Alpha FXM (Hz).
OUTPUT PWR Output Power The Alpha FXM output power in VA (true RMS).
BATT VOLT Battery Voltage The battery output voltage (VDC).
CHGR CUR Charger Current The Alpha FXM battery charging current is set to this value (Amps).
DATE Displayed in the format set by the user.
TIME Displayed in the format set by the user.
INV COUNT # of line failures
Shows how many times the inverter has been active since the last time the
inverter counter was cleared. See INV RECORD description in Table B.
INV (min)
Amount of time
inverter was on
shows total time in minutes the inverter has been active since the last time
inverter timer was cleared. See INV RECORD description in Table B
SHED TIMER1
Amount of
time until the
dry contact is
activated.
The factory default dry contact for this setting is contact C4. SHED TIMER2 and
SHED TIMER3 can be field programmed. See “Setting the Timer Contact”. This
display shows the amount of time left in seconds until the contact is activated.
The factory default setting is 2 hours, but this can be changed as shown in
"Programming the Dry Contacts and the Clock". C4 is available on the FXM350 if
the optional signal assembly is installed—see Section 3.3.2.
SHED TIMER2
SHED TIMER3
MAC Address
Communication
Module's MAC
The Communication Module's MAC address is displayed.
IP Address
Communication
Module's IP
The Communication Module's IP is displayed.
kWh kWh Meter The accumulated output energy is displayed.
Remain Tm
Remaining
Battery Runtime
The remaining runtime of the battery is displayed. Refer to Appendix A to set
battery parameters.
Serial Number
Unit Serial
Number
The unit serial number of the Alpha FXM is displayed.
VERSION Software Version The software version used in this Alpha FXM
