Alpha Technologies FXM350_Micro350 UPS User Manual
Page 101

99
017-241-B0 Rev B
Table S — Electrical Specifications
Parameter
Value
INPUT
Voltage (nominal), Vac
120 or 230
Frequency, Hz, ±5%
60/50 (auto-detection), Output frequency = Input frequency
Current, Amps
(@ nominal Vin and max
battery charging current)
FXM 350-24: 5.3 / 2.7 @120/230 Vac
FXM 350-48: 5.7 / 2.9 @120/230 Vac
AC Input Circuit Breaker
Ratings, Amps
FXM 350-24: 7 / 3.5 @120/230 Vac
FXM 350-48: 7 / 3.5 @120/230 Vac
Battery Circuit Breaker
Ratings, Amps
FXM 350-48: 15
FXM 350-24: 30
OUTPUT
Voltage (nominal), Vac
120 or 230 and 24 Vac
Frequency, Hz, ±5%
60/50 (output frequency = input frequency)
Power, W/VA
350 Total
24 Vac: 260 VA (max)
120 Vac: 350 VA (max)
Waveform
Pure sine wave
Load Crest Factor
3:1 (load dependent)
Output Voltage Distortion
< 3% THD (resistive load)
Efficiency
5
Normal Mode
Backup (Inverter) Mode
> 96%
> 82% (48 Vbatt), >75% (24 Vbatt)
Transfer Time, mS
AVR to Backup
Backup to AVR
5 (typical)
5 (typical)
Line Qualification Time,
Seconds
3 (factory default), user adjustable to 3, 10, 20, 30, 40, or 50
Battery String Voltage
FXM 350 - 24: 24 VDC
FXM 350 - 48: 48 VDC
Battery Charger Current,
FXM 350 – 24: 6A default user adjustable (0~6A)
FXM 350 – 48: 4A default user adjustable (0~4A)
Battery Charger Temperature
Compensation
6
-5 mV/°C/Cell (factory default), user adjustable to -2.5, -4, -5 or -6 mV/°C/Cell
Battery type
Anderson Power mating part PP45 or equivalent
1. Capable of operating at 73% of rated full load for up to 2 hours at 74°C. For FXM350, above 55°C ambient, derate output power by 1.4%
per °C rise, up to 74°C max. For Micro350 derate above 50°C
2. Capable of operating at 100% of rated full load below 0°C down to -40°C after the Alpha FXM350 and Micro350 has been stabilized at
0°C for at least 1 hour. Batteries may need battery heater mat at lower temperatures.
3. Derate 2°C per 300 m (1000 ft) above 1400 m (4500 ft).
4. The LCD display may not function below -15°C. It gradually resumes normal operation as the temperature rises above -15°C. This will not
affect the operation of the Alpha FXM.
5. Efficiency is measured at an ambient temperature of 25°C, full resistive condition and nominal Line and Battery voltage.
