Alpha Technologies FXM350_Micro350 UPS User Manual
Page 81

79
017-241-B0 Rev B
7.5.2.2 Main Menu Screen — Line Status
Line status line reports the line condition. For an updated value, press Enter.
Table E — Line Status (see Figure 67)
Normal The line is within specifications. See specifications, “Boost/Buck/Line Transfer Thresholds”.
The Alpha FXM is operating in Line mode.
Boost Line voltage is out of tolerance. The Alpha FXM is operating in Boost mode.
Buck Line voltage is out of tolerance. The Alpha FXM is operating in Buck mode.
Blackout The line is absent.
Freq low Line frequency is too low.
Freq high Line frequency is too high.
7.5.2.3 Main Menu Screen — Output Status
Output status line reports how the Alpha FXM is producing power. For an updated value, press Enter.
Table F — Output Status (see Figure 67)
Line mode
Battery mode
Battery mode, low bat. warning
Battery mode (testing battery)
Battery bypass mode
Boost mode
Boost 2 mode
Buck mode
Hot swap mode
Inverter off due to fault
Inverter off due to low battery
Inverter off at start-up
Shutdown due to user request
