Before You Begin — Planning the Installation
Before installation is started, you must be consider several major factors to ensure that the
installation process is as smooth and trouble free as possible, and so that the final finished
project meets the needs of the customers, users, audiences, and installer.
The installation considerations on the following pages, though not comprehensive, should
be consulted to help ensure that key installation aspects have been considered.
Americans with Disabilities Act (ADA) Compliance
When planning where to install the Polevault System, you may need to consider factors
affecting accessibility of the system such as the height of devices from the floor (for example
the MLC controller), distance from obstructions, and how far a user must reach to press any
device buttons.
For guidelines, see sections 307 (“Protruding Objects”) and 308 (“Reach Ranges”) of the
2010 ADA Standards for Accessible Design available at
Room Layout
a. The Room
The application diagram below shows a typical classroom installation.
CONFIG
DISPLAY
VOLUME
1
2
3
4
ON
OFF
VCR
DVD
PC
Extron
MLC 104 IP Plus
PoleVault System
CONFIG
DISPLAY
VOLUME
1
2
3
4
ON
OFF
VCR
DVD
PC
Extron
MLC 104 IP Plus
PoleVault Syste
Figure 2.
Typical Classroom Installation
Room factors to be considered should include, but are not confined to:
•
Room size, orientation, and layout:
•
Audience factors (for example number, ADA requirements, seating arrangements)
•
Existing installed furniture (bookcases, racks, cabinets, workbenches, sinks, and so
forth.)
•
Windows, doors, and support pillar locations in relationship to the proposed screen
location
