Installation overview – Extron Electronics PoleVault IP Systems PVS 305SA IP User Manual
Page 13
Installation
Overview
This overview outlines the basic steps for installing the PoleVault IP System. An outline and
checklist of the stages (Stages One through Five), listing the relevant steps within each
stage, is given on page 10 and rear cover.
A fully detailed description of these steps is given in the five corresponding sections.
Carefully check inventory of PoleVault IP System packages, input and output devices, any
optional accessories, and installation hardware before commencing.
NOTES:
•
Additional installation hardware is needed for this installation, and should be
supplied by the installer. See
on page 8 for a list of items that
you may need.
•
Refer to local building standards and codes to verify that the installation will meet all
the regulatory requirements.
•
Observe all local and national building and safety codes, UL requirements, and
ADA Accessibility Guidelines.
PoleVault IP Systems • Installation Overview
9
