Outline of Installation Steps
Stage 1 — Install the Screen and Projector
c Mark the screen location (page 12) .
c Install projector to verify location (page 12 ).
c Verify the image location (page 15) .
c Cut the ceiling tile (page 16) .
c Preliminary safety hardware installation (page 16) .
c Finish projector drop ceiling mount installation (page 17).
c Secure the projector drop ceiling mount to the ceiling (page 18) .
c Install the electrical box (if required) (page 19) .
c Install the screen (page 19) .
Stage 2 — Mount the PVT Wall Plates and the MLC 104 IP Plus.
c Install the mud rings (page 23) .
c Pull cables (at the input locations) (page 24) .
c Install the wall plates (page 25) .
c Install the MediaLink Controller (page 26) .
Stage 3 — Install the FF 120 Speakers.
c Cut the ceiling tile (page 30) .
c Install the speaker on the drop ceiling (page 30).
c Terminate the speaker cable for the PVS switcher (page 32).
Stage 4 — Install the PMK 550 and the PVS 305SA IP.
c Install the PMK 550 base plate (page 34) .
c Pull the cables (at the switcher location) (page 35).
c Finish installing the pole mount kit (page 36) .
Stage 5 — Configure the PoleVault Switcher and the System.
c Configure the switcher — MLS Switcher Configuration program (page 37) .
c Configure the system — Global Configurator (page 38) .
c Test the system (page 39).
c Final installation (page 41) .
