Extron Electronics PoleVault IP Systems PVS 305SA IP - Manual (Page 32)

d. The connections between the MLC 104 IP Plus
and the PVS 305SA IP switcher should look like
the figure at right.
e. Sliding the cables into the opening, secure
the MLC 104 IP Plus to the mud ring with the
provided machine screws.
4.06"
3.75"
Wall Mouting
Bracket
Rotate locking arm
and insert into wall
opening.
Extron
MLC 104 IP Plus
Wall
OFF
ON
OFF
ON
CONFIG
DISPLAY
VOLUME
1
2
3
4
MLC 104 IP Plus
ô
Secure the MLC 104 IP Plus to the mud ring
ò
Connections made to the MLC 104 IP Plus
PVS 305SA IP Switcher Rear Panel
L R L R
L R
AUX AUDIO
INPUT 5
LINE OUT
VOICELIFT RECEIVER
PAGING SENSOR
DO NOT GROUND OR SHORT SPEAKER OUTPUTS
1B RGB
1A RGB
2B RGB
2A RGB
3B RGB /VIDEO 4B RGB /VIDEO
3A RGB 4A RGB
I
N
P
U
T
S
RS-232 MLC/IR
2/4/8 Ohms
CLASS 2 WIRING
AMPLIFIED AUDIO OUT
VOL/MUTE
Tx Rx IR 12V 10V 50mA
POWER RGB VIDEO OUTPUTS
CONTROL
N15779
12V
5A MAX
LAN 3 LAN 4
LAN 1 LAN 2
TCP/IP
Network
1 2 3
GR
O UND
+12V OU
T CM
GR
O UND
IR OU
T
GR
O UND SCP
GR
OUND
Tx Rx
DISPLAY
RS-232/IR
A B C D E
COMM LINK
LAN
PRESS TAB WITH
TWEEKER TO REMOVE
A B
MLS
RS-232
POWER
12V
DIGITAL
I/O
IR IN
Tx
GR
OUN
D Rx
+12V IN
MLC 104 IP Plus Right Side Panel
Projector
RS-232
and Power
4c 4a
4b RS-232 Control
CAT 5 Cable
PoleVault IP Systems • Installation — Stage 2 (Wallplates and MLC) 28
