Audio Adjustment area
z Audio Gain/Attenuation — A slider control enables you to
adjust the input audio gain or attenuation value from –18 dB to
+10 dB in 1.0 dB increments.
NOTE: Changes to the input gain or attenuation are made
in the transmitter. If your computer is connected to
the receiver and Link 2 is not active, the gain and
attenuation values are grayed out and cannot be
changed.
z Audio Output Level — Select Consumer Level (–10 dBV)
or Professional Level (+4 dBu) radio button for the audio
output.
Updating Firmware
Firmware can be upgraded for the transmitter and the receiver unit via the PowerCage
Config port using the Extron Firmware Loader utility from the FOX Extenders control
program. The firmware can be downloaded to your computer from the Extron website
(
www.extron.com ) and uploaded to the unit. The transmitter and receiver require
different firmware and must both be upgraded separately.
NOTES: • When firmware upgrades are available, they are unique to the unit — a
transmitter firmware upgrade for the Tx unit and a separate receiver
upgrade for the Rx unit.
• Your computer must be connected directly to the unit for the firmware to be
updated.
Downloading the Firmware from the Website
To obtain the latest version of firmware for your PowerCage FOX Tx/Rx AV:
1. Visit the Extron website, www.extron.com , click the Download tab, and then click
the Firmware link on the left sidebar menu.
1
1
Figure 20. Link to the Firmware Upgrade Files
2. On the Download Center screen, click the links for the appropriate firmware file.
3. Complete the Personal Information form and click the Download filename button.
PowerCage FOX Tx/Rx AV • Remote Communication and Control 30
