Picture adjustments, continued
Video mute:
Enable mute
1B
Blk1
]
Mute the selected input.
Disable mute
0B
Blk0
]
Disable mute on the selected input.
View current blanking
status
B
X%]
Display current blanking status
X%
.
For
X%
:
0 = Disable blanking or mute.
1 = Enable blanking or mute.
Output video format
Specify output format
6*
X1%
#
Syn
X1%]
Set format
X1%
of the output video
signal. For
X1%
:
0 = Follow input type (default)
6 = Component
7 = S-Video
8 = Composite
View current output
setting
6#
X1%]
Display current output video format
X1%
.
Memory presets
Recall Preset
X1)
.
Rpr
X1)]
Recall memory preset
X1)
.
A period (.) follows
X1)
in the
command.
X1)
= 1 through 30
Save Preset
X1)
,
Spr
X1)]
Save memory preset
X1)
.
A comma (,) follows
X1)
in the
command.
Audio mute
Enable audio mute
1Z
Amt1
]
Mute the audio.
Disable audio mute
0Z
Amt0
]
Unmute the audio.
View mute status
Z
X%]
Display current audio mute status
X%
.
For
X%
:
0 = Unmute audio.
1 = Mute audio.
Audio gain and attenuation
Set audio gain
X1!
G
Aud
X1*]
Set value
X1!
of the audio gain. Use
only uppercase G for configuring
gain. The unit responds with gain
level
X1*
.
X1!
= 0 through 10 dB
X1*
= 0 through 10
Default = 0.
Set audio attenuation
X1@
g
Aud
X1(]
Set value
X1@
of audio attenuation.
Use only lowercase g for configuring
attenuation. The unit responds with
attenuation level
X1(
.
X1@
= 0 through –18 dB
X1(
= 0 through –18
Default = 0.
