Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Audio gain and attenuation, continued
Increment audio level +G
+g Aud X1#]
Aud X1#]
Increase the gain (G) or attenuation
(g) of audio level
X1# by 1 dB.
X1# = –18 through +10 dB.
Default = 0.
Decrement audio level -G
-g Aud X1#]
Aud X1#]
Decrease the gain (G) or attenuation
(g) by 1 dB. Audio level
X1# = –18
through +10 dB.
View current audio
level G
g Aud X1#]
Aud X1#]
Display current value Audio level X1#
for gain (G) or attenuation (g).
Audio output level
Set to consumer level 40*0# Lvl0 ] Set the audio output to the
consumer level: –10 dBV
(default level).
Set to professional
level 40*1# Lvl1 ] Set the audio output to the
professional level: +4 dBu
View current output
level status 40# X%] Display current audio output level X% .
For X% :
0 = consumer level
1 = professional level
Auto Memory
Disable Auto Memory 55*0# Img0 ] Disable Auto Memory.
Enable Auto Memory 55*1# Img1 ] Enable Auto Memory (default).
Parameters saved are color, tint,
brightness, and contrast.
View current Auto
Memory setting 55# X%] View current Auto Memory setting
X% . For X% : 0 = disabled; 1 = enabled
Auto-Image ™
Trigger 55*2# Img ] Trigger Auto-Image for the current
input. Parameters adjusted are color,
tint, brightness, and contrast.
Test pattern
Color Bars 1J Tst1 ] Select the Color Bars pattern.
Grayscale 2J Tst2 ] Select the grayscale pattern.
Alternating pixels 3J Tst3 ] Select the alternating pixels pattern.
Off 0J Tst0 ] Select no test pattern.
View current test
pattern status J X1&] Show current test pattern X1& . For
X1& :
0 = Test pattern off (default)
1 = Color Bars
2 = grayscale
3 = alternating pixels
PowerCage FOX Tx/Rx AV • Remote Communication and Control 21
