Extron Electronics PowerCage FOX Tx_Rx AV User Guide User Manual
Page 29
Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Status Request
View Link 1 Status
1S
X%]
Displays Link 1 status
X%
. For
X%
:
0 = no link
1 = link present
View Link 2 Status
2S
X%]
Display Link 2 (return link) status
X%
.
View input video status
3S
X%]
Display input video status
X%
. For
X%
:
1 = a video signal is present.
0 = no video signal is present.
View input audio status
4S
X%]
Display input audio status
X%
. For
X%
:
1 = an audio signal is present.
0 = no audio signal is present.
View internal
temperature
20S
X2#]
Display internal temperature
X2#
in
degrees F and C.
Reset to factory defaults
System Reset (factory
default)
E
ZXXX
}
Zpx
]
Reset unit to all factory default
values.
Reset audio settings
E
ZA
}
Zpa
]
Reset all audio settings to factory
default values
Reset presets
E
ZG
}
Zpg
]
Reset all memory presets to factory
default values
PowerCage FOX Tx/Rx AV • Remote Communication and Control
23
