Command/Response Table for SIS Commands
Command
ASCII Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Picture adjustments
Input video format:
Input video type
X!
\
Typ
X!]
Set format
X!
for the selected input
video signal type. For
X!
:
0 = Auto (default)
4 = Component
5 = S-video
6 = Composite
View current input
setting
\
X!]
Display the current input video
format.
Color:
Color value
X*
C
Col
X*]
Select color value
X*
.
X*
= 0 through 127. Default = 64.
Increment color value
+C
Col
X*]
Select the next higher color value
(increase color value by 1).
Decrement color value
–C
Col
X*]
Decrease color value
X*
by 1.
View current color
value
C
X*]
Display current color value
X*
.
Tint:
Specify tint value
X*
T
Tin
X*]
Set tint value
X*
for the video signal.
X*
= 0 to 127. Default = 64.
Increment tint value
+T
Tin
X*]
Increase tint value
X*
by 1.
Decrement tint value
–T
Tin
X*]
Decrease tint value
X*
by 1.
View current tint value
T
X*]
Display current tint value
X*
.
Contrast:
Specify contrast value
X*
^
Con
X*]
Set contrast value
X*
for the video
signal.
X*
= 0 to 127. Default = 64.
Increment contrast
value
+
^
Con
X*]
Increase contrast value
X*
by 1.
Decrement contrast
value
–
^
Con
X*]
Decrease contrast value
X*
by 1.
View current contrast
value
^
X*]
Display current contrast value
X*
.
Brightness:
Specify brightness
value
X*
Y
Brt
X*]
Set brightness value
X*
for video
signal.
X*
= 0 through 127.
Default = 64.
Increment brightness
value
+Y
Brt
X*]
Increase brightness value
X*
by 1.
Decrement brightness
value
–Y
Brt
X*]
Decrease brightness value
X*
by 1.
View current brightness
value
Y
X*]
Display current brightness value
X*
.
