Operation
After the transmitter, all receivers, and their connected devices are powered up, the
system is fully operational. If any problems occur, verify that the cables are routed and
connected properly and that all display devices have identical resolutions and refresh rates.
If problems persist, call the Extron S3 Sales & Technical Support Hotline. See the
contact
numbers
on the last page of this guide for the Extron office nearest you.
To take advantage of the various adjustments and test patterns available on the
PowerCage FOX Tx/Rx AV, connect a computer or other RS-232 capable device to the
Remote/RS-232 port on either board or to the Config port on the PowerCage 1600 front
panel and operate the system using either
PowerCage FOX Tx/Rx AV • Installation and Operation
14
