DIP switches
Using the table on the two following pages, select the voltage
that is closest to the control voltage of the amplifer or mixer (see
"Determining the Control Voltage" on pages 2-3 to 2-7). Note the
configuration of the DIP switches that is needed to achieve that
voltage and set the DIP switches on the rear panel of the MLA-
VC10 in that configuration.
N
The switch must be fully up or fully down. An
intermediate setting causes the MLA-VC10 to oscillate
erratically between the two possible values.
3
4
1
2
7
8
5
6
3
4
1
2
7
8
5
6
ON
CONFIGURATION
0 to 10.0 VDC
0 to 4.98 VDC
NOT HALFWAY
UP
DOWN
CONFIGURATION
