The page consists of a matrix of input (rows) and output (columns) buttons of two colors:

The

amber buttons indicate ties.

The

gray buttons indicate no ties.

TIP: If you lose track of the input and output associated with a specific button, let the

mouse pointer rest over the button for a moment. As shown on

figure 46

, on the

previous page, a field pops up that identifies the input and output numbers for that
button.

Creating or deleting a tie

Make or break a tie as follows:

1.

Move the mouse over the matrix of input and output selection buttons. Click a button
to:

Create a pending tie (if a tie does not exist) of the input and output associated with
that button.

Create a pending untie (if a tie exists) of the input and output associated with that
button.

A “

P

” (for pending) appears in the button.

NOTES:

Because of command length limitations in the browser, you can make a
maximum of 30 connections with a single

Take

command (step

2).

To tie an input to all outputs, click the input number for that input.

2.

Click the

Take

button to make the configuration changes or the

Cancel

button to

abandon the configuration changes.

FOX Matrix 320x and FOX Matrix 14400 • HTML Operation

73
