Reset Button and LED

e

Reset button (see

figure 3

on page 8 and

figure 4

on page 9)

RESET

The recessed Reset button initiates four levels of matrix switcher reset. For four
different reset levels, press and hold the button while the switcher is running or
while you power up the switcher (see

Reset Operations

on page 18 for details).

Events (mode 3) reset — Toggles events monitoring on and off.

IP settings (mode 4) reset — Reset the IP functions of the switcher.

NOTE: The IP settings reset does not replace any user-installed firmware.

Absolute (mode 5) reset — Restore the switcher to the default factory conditions.

Hard reset — Restore the switcher to the default factory conditions and return the
switcher to the default firmware that shipped with the unit.

NOTES:

Factory loaded firmware is active until it is replaced or the power is cycled.

Hard reset does not clear the current configuration.

Power Supply Modules and Indicator LEDs

f

Primary and Redundant AC power connectors (see

figure 3

and

figure 4

) —

Plug standard IEC power cords into these connectors to connect the switcher to
100 VAC to 240 VAC, 50 or 60 Hz power sources.

NOTE: For the most reliable power, connect the a power cord from the Redundant

power connector to either an uninterruptible power source or to a power source
that is completely independent from the primary power source.

g

Primary and Redundant power supply indicator LEDs (see

figure 3

and

figure 4

) —

Green — Indicates that the associated power supply is operating within normal
tolerances.
Red — Indicates that the associated power supply is operating outside the normal
tolerances or has failed. See

Removing and Installing a Power Supply Module

on

page 78 to replace the power supply.

Cooling Fan assemblies

i

Primary and Redundant cooling fans (see

figure 3

and

figure 4

) — Cool the

equipment. If a fan has failed, replace it at your earliest opportunity. See

Removing and

Installing a Fan Module

on page 80 to replace the fans.

FOX Matrix 320x and FOX Matrix 14400 • Installation

15
