DVCM 50 • Specifi cations, Part Numbers, and Accessories A-2
Specifi cations, Part Numbers, and Accessories
PRELIMINAR
Y
Specifi cations
Control/remote — controller host port
Serial control port ......................... 1 rear panel 2.5 mm mini stereo jack (tip-ring-sleeve)
Baud rate and protocol ............... 9600 baud, 8 data bits, 1 stop bit, no parity
Serial control pin confi gurations . Mini stereo jack: tip = TX, ring = RX, sleeve = GND
Program control ............................. Extron’s confi guration program for Windows®
Extron’s Simple Instruction Set (SIS™)
Control — peripheral equipment
IR transport connector .................. (1) 3.5 mm captive screw connector, 5 pole for IR control (port is shared with
power input)
IR control ........................................ TTL level (0 to 5 V) modulated infrared control from 30 kHz up to 60 kHz
IR learning frequencies ................. 30 kHz to 62 kHz
IR learning distance ...................... 4” (10 cm) to 14” (36 cm) from the side panel
General
Power .............................................. 12 VDC from an Extron MLC 104 or MLC 104 IP
or from an optional external power supply
External power supply (optional) 100 VAC to 240 VAC, 50/60 Hz, external, autoswitchable; to 12 VDC, 1 A,
regulated
Power input requirements ........... 12 VDC, 0.05 A
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount .................................... Yes, with optional rack mounting kit, and also wall- and furniture-
mountable with optional faceplates or AAP wall plates
Enclosure type .............................. Metal
Enclosure dimensions
Faceplate ............................. 2.8” H x 3.5” W x 0.1” D (7.1 cm H x 8.9 cm W x 0.3 cm D)
(four space AAP plate)
Boards ................................ 2.7” H x 2.6” W x 0.9” D (6.9 cm H x 6.6 cm W x 2.3 cm D)
(Depth excludes buttons. Allow at least 2.1” (5.3 cm) depth in the wall/
furniture.)
Product weight .............................. 0.2 lbs (1 kg)
Shipping weight ............................ 1 lbs (1 kg)
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Listings............................................ UL, CUL
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................... 30,000 hours
Warranty ........................................ 3 years parts and labor
All nominal levels are at ±10%.
Specifi cations are subject to change without notice.
