Confi guration and Operation, cont’d

DVCM 50 • Confi guration and Operation

3-4

PRELIMINAR

Y

6

DVD and VCR control buttons

— These buttons may be used to control both a

DVD and a VCR. The buttons can be programmed via IR Learning, data transfer,
or the Windows-based confi guration software to perform the functions for which
they are labeled. Each of these buttons has eight memory blocks (four available in
DVD mode and four for VCR mode), which can be programmed with commands.

Other buttons on the front panel

The remaining front panel buttons are typically programmed to initiate the functions
with which they are labeled. Except for

Tuner

S and T, the buttons listed below are

available in either DVD mode or VCR mode; they do not function in both modes. Each
of these buttons has four memory blocks that can be programmed with commands.

The buttons on the DVCM 50 front panel are labeled with the names of functions

that are typically found on a DVD player or a VCR and their remote controls.
However, if desired, you can program these buttons with different functions.

TV/VCR —

(VCR mode only) Program this button with the IR command that

causes the VCR to switch between operating as a TV tuner and operating as
a VCR. This button can be programmed and can issue IR commands only in
VCR mode

.

Title

— (DVD mode only) Program this button with the IR command that displays

the main menu on the display device screen. This button can be programmed
and can issue IR commands only in DVD mode.

Enter

— (DVD mode only) Program this button with the IR command that selects

items from the DVD’s on-screen menu. This button can be programmed and
can issue IR commands only in DVD mode.

Menu

— (DVD mode only) Program this button with the IR command that

displays the DVD menu on your display device. This button can be
programmed and can issue IR commands only in DVD mode.

Tuner

W and X — (DVD mode only) Program these buttons with the IR command

that moves the cursor right or left on the screen in order to select menu
items or function icons. These buttons can be programmed and can issue IR
commands only in DVD mode.

Tuner

S and T —

VCR mode:

Switches TV channels up and down when the VCR is in tuner

mode.

DVD mode:

When programmed, moves the cursor up and down between

menu items or other items on the screen.

Programming the DVCM 50 Using IR

The DVCM 50 can be programmed/confi gured via IR by the following methods:

IR learning from your DVD or VCR remote control

IR data transfer from another DVCM 50 that has been confi gured previously
