DVCM 50 • Introduction

1-2

Introduction

PRELIMINAR

Y

About this Manual

This manual contains installation, confi guration, and operating information for the
Extron DVCM 50 DVD/VCR Control Module.

The terms “DVCM,” “DVCM 50,” and “control module” are used

interchangeably in this manual to refer to the DVCM 50 DVD/VCR Control
Module.

About the DVCM 50 DVD/VCR Control Module

The DVCM 50 DVD/VCR Control Module is a four-space Architectural Adapter
Plate (AAP) module that is used for controlling DVDs and VCRs. It can be used
with an MLC 52 or MLC 104 MediaLink Controller, or as a standalone control
module, sending IR signals directly to the DVD or VCR. The DVCM 50 can be
confi gured by the following methods:

• IR Learning from a DVD or VCR remote control

IR data transfer (beaming) from another DVCM that has been confi gured

• Using IR drivers that have been downloaded using the Extron’s Windows

®

-

based confi guration software program

Features

Standalone operation available

If desired, the DVCM 50 can be used as a

standalone unit without connection to, or dependence on, a system switcher
or MediaLink controller.

Macro and toggle button mode

s Each button can be set to send out multiple

IR commands. A button confi gured for macro mode can issue up to four
commands in sequence from a single button press. A button confi gured for
toggle mode can issue up to four different commands, sending out a different
command each time the button is pressed.

Front panel confi guration port

This serial port enables advanced confi guration,

driver downloads, and fi rmware updates to be performed from the front
panel without the need to remove the control module from its mounting. The
optional Extron confi guration cable (part #70-335-01) connects the DVCM 50
to the PC’s RS-232 port.

Three confi guration methods —

The DVCM 50 can be confi gured easily using the

following methods:

IR Learning Allows the DVCM 50 to be set up directly from the DVD or

VCR remote control without the need for software.

IR data transfer (“beaming”) Duplicates complete confi guration

information from one DVCM 50 to another without cables or software.

Windows-based confi guration software Combined with one of the many

IR drivers available on the Extron Web site, Extron’s MLC 52/DVCM 50
Control Program software provides fast and simple setup.

Front panel security lockout

Front panel lockout (executive mode) can be

implemented if the DVCM 50 is installed in an unsecured environment where
easy access is not desirable.
