Preliminar y – Extron Electronics DVCM 50 User’s Manual User Manual
Page 39
4-9
DVCM 50 • Special Application
PRELIMINAR
Y
Volume control on the MLC 104
To control the volume on the MLC 104 using the IR 452, press the rocker button
in the Display section. Pressing the up or down arrow on this button causes the
DVCM 50 to send a +V or –V SIS command to the MLC 104, which responds by
increasing or decreasing the volume on the display device.
Remove the Volume label from the sheet of labels provided with the IR 452, and
affi x it above the arrow rocker button on the IR 452 front panel as shown in the
illustration below.
SYSTEM REMOTE
FRONT PANEL
DVD
VCR
DVD
VCR
TV/VCR
VOL
VOL
PC
VIDEO
CHANNEL
IR 452
POWER
ON
VOLUME
Labeling the MLC 104 Volume buttons on the IR 452
