Push Configuration - Advanced,

Push Presets, All

There are a number of advanced
options available when pushing
a configuration that enable the
user to tailor the input, signal
processing, signal mix, or output
to a specific preset operation.
This allows the user to push the
currently open configuration,
including all presets, to the
DMP 44 LC or to customize
the push to include either the
configuration, selected presets,
or both.
To use the advanced push
feature:
Connect the DMP 44 LC as
described by steps 1 to 4 in the
previous procedure for switching
from Emulate mode to Live mode
(see “

To switch from emulate

mode to live mode:

”), then:

1.

Select the Push radio
button, then click

Advanced.

NOTE: Clicking

OK at this

time pushes the
currently open
configuration to the
DMP 44 LC.

2.

The program asks you to
choose an option:

a.

Choose

Default

to update the

device configuration
with the currently open
file. Proceed to step 4.

b.

Choose

Custom

for additional
options

.

Proceed to

step 3.

NOTE: In either case, the

program and device
configuration now
reflect DSP Configurator
changes to the DMP 44 LC
configuration in real-time.

1

1

2a

2b

3a

5

6

4

3b
