Extron Electronics DMP 44 LC User Guide - Manual (Page 56)

Table 1. Level Control and Mix-point Selection Tables
a Input Gain Control
X6)
b Pre-mixer Gain
X6)
Input 1 30000 Input 1 30100
Input 2 30001 Input 2 30101
Input 3 30002 Input 3 30102
Input 4 30003 Input 4 30103
c Main Mix-point
X6)
c Main Mix-point
X6)
Input 1 to Output 1 20000 Input 2 to Output 1 20100
Input 1 to Output 2 20001 Input 2 to Output 2 20101
Input 1 to Output 3 20002 Input 2 to Output 3 20102
Input 1 to Output 4 20003 Input 2 to Output 4 20103
c Main Mix-point
X6)
c Main Mix-point
X6)
Input 3 to Output 1 20200 Input 4 to Output 1 20300
Input 3 to Output 2 20201 Input 4 to Output 2 20301
Input 3 to Output 3 20202 Input 4 to Output 3 20302
Input 3 to Output 4 20203 Input 4 to Output 4 20303
d Post-mixer Trim
X6)
To Output 1 60100
To Output 2 60101
To Output 3 60102
To Output 4 60103
e Post-mixer Output
Volume
X6)
To Output 1 60000
To Output 2 60001
To Output 3 60002
To Output 4 60003
DMP 44 LC • SIS Programming and Control 50
