Digital Input Commands
Command ASCII Command
(Host to Tuner)
Response
(Tuner to Host)
Additional Description
Configure digital input E X! * X@ * X# * X$ GPIT } GPIT X! * X@ * X# * X$ ] See table below
View digital input E X! GPIT }
Vrb mode 2/3:
X@* X#* X$ ]
GPIT X! * X@* X#* X$ ]
View digital input
View I/O state X!*]
Vrb mode 2/3:
X% ]
Sio X! * X%
View I/O state
Digital Input Command Table
X!
= Digital inputs 1–3 Inputs 1–3
X@
= Type of signal change to monitor for 0 = off (default) 3 = level lo
1 = edge, hi to lo 4 = level hi
2 = edge, lo to hi
X#
= Function 0 = off (default) 3 = decrement group
1 = mute/unmute group 4 = preset recall
2 = increment group
X$
= Preset or group number preset range = 1–16
group range = 1–16
0 = off (default)
X% = State 0 = hi (voltage)
1 = lo (voltage)
DMP 44 LC • SIS Programming and Control 45
